OMNITRONIC 80709786 MPVZ-250.6 PA Mixing Amplifier
Description
6-zone PA mono mixing amplifier, 250 watts, adjustable zones
- Comfortable control of PA speakers via 6-zone technology
- 6 PA zone outputs with separate 5-step level controls
- Master PA output (70 V and 100 V)
- Output for low-impedance speakers (4-16 ohms)
- 2 rear microphone inputs (6.3 mm jack, unbal.)
- 1 front microphone input (combination XLR/6.3 mm jack, unbal.) with adjustable priority circuit
- All microphone inputs with separate level controls
- 3 line inputs (stereo RCA) with separate level controls
- 1 line output (stereo RCA)
- Chime, switchable
- Treble and bass control for the output signal
- 7-fold LED level display
- Master control for the output signal
- Fan-cooled
- Protection circuits with LED indication: over current, short circuit, turn-on delay
- Housing design: (19″) 48.3 cm rack installation 2 U
Specifications
| Power supply: | 230 V AC, 50 Hz |
| Power consumption: | 500.00 W |
| Output power: | 250 W RMS |
| Power connection: | Fixed Power supply cord with safety plug |
| Frequency range: | 80 – 16000 Hz |
| S/N ratio: | >75 dB Microphone; >85 dB line |
| Impedance: | 4 Ohm; 8 Ohm; 16 Ohm; 100 V ELA |
| Equalizer: | master: 1 x 2-band tone control Mono |
| Circuitry: | Class AB |
| Controls: | current limiting; short-circuit; power on/off transient |
| Indicators: | power, fault, level meter |
| Connections: | Input: 1 x Microphone via 3-pin XLR/6.35mm jack (F) combination socket (mounting version) |
| Input: 2 x Microphone via 6.3 mm plug (unbal.) | |
| Input: 3 x line via Stereo RCA 0.3 V | |
| Output: 1 x line via Stereo RCA | |
| Output: Speakers via screw terminal | |
| Distortion: | <0.5 % |
| Housing design: | (19″) 48.3 cm rack installation 2 U |
| Width: | 48.3 cm |
| Height: | 8.9 cm |
| Depth: | 38.5 cm |
| Weight: | 11.15 kg |
