LD Systems SP 44K

PA Power Amplifier 4 x 980 W 2 Ohm

LD Premium LDSP44K 4-Channel Power Amplifier

The LDSP44K is a professional 4-channel power amplifier offering amazing value and versatility in a compact lightweight Class H design. Suitable for touring and installation sound reinforcement it delivers a maximum of 4x 980W into 2Ohms and 2x 1.960 in 4Ohms stereo bridge mode.

Featuring a high efficiency switch mode power supply the LDSP44K provides a 20Hz – 20kHz bandwidth with low THD and crosstalk, a damping factor higher than 500, excellent S/N ratio and 3 switchable sensitivity levels.

Reliable performance is ensured by heavy duty engineering, high quality components and comprehensive protection including soft start with turn-on muting, PMS™ power management, SSP™ (Safe operation Sentry Protection) and ICL™ (Intelligent Clip Limiting) to maintain signal integrity. Protection circuits against DC, thermal and power supply overload are implemented. A switchable subsonic filter and a 3-position gain switch offer variable amplifier adjustment.

Type
PA Power Amplifiers

Rated ouput power (1kHz @ 2 Ohms)
4 x 980 W

Rated ouput power (1kHz @ 4 Ohms)
4 x 670 W

Rated ouput power (1kHz @ 8 Ohms)
4 x 430 W

Rated ouput power (1kHz @ 4 Ohms, bridged)
2 x 1960 W

Rated ouput power (1kHz @ 8 Ohms, bridged)
2 x 1340 W

Output circuitry
Class H

Frequency response
20 – 20000 Hz

Total Harmonic Distortion (THD)
< 0.05 %

Signal-to-noise ratio
113 dB

Damping factor
> 500

Crosstalk
>75 dB

Gain
26 / 32 / 38 dB

Input sensitivity
3.0 / 1.5 / 0.8 V

Protection circuits
DC , ICL (Intelligent Clip Limiting) , mute when turning on , Open or mismatched loads , PMS , power supply overload , short circuit , soft start , SSP , thermal protection

Controls
bridge/stereo mode selector , dual/link switch , gain , mains switch (on/off) , volume

Indicators
ICL (Intelligent Clip Limiting) , PMS , Signal , temperature

Loudspeaker outputs
4

Speaker output connections
Speakon

Cooling
2 fans, continuous speed

Operating voltage
Switching power supply

Power consumption @ full load
13.5

Operating voltage
220 V AC – 240 V AC, 50-60 Hz

Width
483 mm

Height
89 mm

Depth
310 mm

Weight
8,5 kg
