Eminence Red White and Blues – EPRWBA
Καλέστε μας για τιμή
Eminence Red White and Blues – EPRWBA
Κατόπιν παραγγελίας
- Περιγραφή
Περιγραφή
Eminence Red White and Blues – EPRWBA
Coloration: Nice tight low-end, s mooth midrange and top end sparkle. American cousin to The Governor
Genre : Classic American Rock tone of the 60’s and 70’s
Product type
Loudspeaker Chassis
Nominal Diameter
12 “
Nominal Diameter
304.8 mm
Voice Coil
1.75 “
Voice Coil
44.5 mm
Overall diameter
305.3 mm
Pitch Circle Diameter
295.4 mm
Section Diameter
278.6 mm
Diameter of fixing holes
6.4 mm
Depth
130 mm
Nominal Impedance
8 Ohm(s)
Nominal Load Capacity
120 W
Sensitivity (1 W / 1 m)
101 dB
Frequency response
70 – 4500 Hz
Voice Coil Material
copper
Magnet
Ferrite
Depth of the magnetic gap
7.92 mm
Thiele & Small Parameter
Fs (Resonance Frequency)
110 Hz
Re (DC resistance)
6.42 Ohm(s)
Qms (mechanical quality)
7.19
Le (inductance of the voice coil)
0.43 mH
Qes (electrical quality)
0.89
Qts (overall quality)
0.79
Vas (equivalent volume)
30.8
Mms (moving mass)
30 g
BL (power factor)
12.3 T/m
Xmax (maximum displacement)
0.8 mm
Cms (elasticity of the suspension)
0.07 mm/N
Sd (membrane area)
558.6 cm²
Weight
4,58 kg
