Eminence Lil Buddy
Καλέστε μας για τιμή
Eminence Lil Buddy
Κατόπιν παραγγελίας
- Περιγραφή
Περιγραφή
Eminence Lil Buddy
Coloration : A clean and full tone, slow to break-up, but crunchy when driven. Smoother and less defined than many guitar speakers.
Genre : Jazz and Blues
Product type
Loudspeaker Chassis
Type
Guitars
Nominal Diameter
10 “
Nominal Diameter
254 mm
Voice Coil
1.75 “
Voice Coil
44.5 mm
Overall diameter
256.8 mm
Pitch Circle Diameter
243.8 mm
Section Diameter
231.8 mm
Diameter of fixing holes
5.7 mm
Depth
109 mm
Nominal Impedance
8 Ohm(s)
Nominal Load Capacity
50 W
Sensitivity (1 W / 1 m)
99.1 dB
Frequency response
80 – 5000 Hz
Voice Coil Material
copper
Magnet
Ferrite
Depth of the magnetic gap
7.92 mm
Thiele & Small Parameter
Fs (Resonance Frequency)
149 Hz
Re (DC resistance)
6.31 Ohm(s)
Qms (mechanical quality)
9.06
Le (inductance of the voice coil)
0.46 mH
Qes (electrical quality)
0.93
Qts (overall quality)
0.84
Vas (equivalent volume)
10
Mms (moving mass)
22 g
BL (power factor)
11.7 T/m
Xmax (maximum displacement)
0.8 mm
Cms (elasticity of the suspension)
0.05 mm/N
Sd (membrane area)
366.1 cm²
Weight
3,36 kg
