Eminence Legend B 810
Καλέστε μας για τιμή
Eminence Legend B 810
Κατόπιν παραγγελίας
- Περιγραφή
Περιγραφή
Eminence Legend B 810
10″ Speaker 150 W 32 Ohms
Product type
Loudspeaker Chassis
Type
Guitars
Nominal Diameter
10 “
Nominal Diameter
254 mm
Voice Coil
2 “
Voice Coil
50.8 mm
Overall diameter
256.8 mm
Pitch Circle Diameter
243.8 mm
Section Diameter
231.8 mm
Diameter of fixing holes
5.7 mm
Depth
103.6 mm
Nominal Impedance
32 Ohm(s)
Nominal Load Capacity
150 W
maximum rated load
300 W
Sensitivity (1 W / 1 m)
92.7 dB
Frequency response
49 – 5100 Hz
Voice Coil Material
copper
Magnet
Ferrite
Depth of the magnetic gap
7.94 mm
Thiele & Small Parameter
Fs (Resonance Frequency)
52.07 Hz
Re (DC resistance)
27.5 Ohm(s)
Qms (mechanical quality)
13.91
Le (inductance of the voice coil)
2.72 mH
Qes (electrical quality)
0.68
Qts (overall quality)
0.65
Vas (equivalent volume)
66.4
Mms (moving mass)
23.8 g
BL (power factor)
17.8 T/m
Xmax (maximum displacement)
4.7 mm
Cms (elasticity of the suspension)
0.39 mm/N
Sd (membrane area)
350.1 cm²
Weight
3,58 kg
