EMINENCE – Kappa Pro 15 A
KAPPA PRO-15A Professional SeriesRecommended for professional audio in a vented mid-bass or bass enclosure. Also suitable for bass guitar.
Product type
Loudspeaker Chassis
Type
PA
Nominal Diameter
15 “
Nominal Diameter
381 mm
Voice Coil
3 “
Voice Coil
76.2 mm
Overall diameter
389.1 mm
Pitch Circle Diameter
369.9 mm
Cut- out Measurement
355.6 mm
Diameter of fixing holes
7.1 mm
Depth
154 mm
Nominal Impedance
8 Ohm(s)
Nominal Load Capacity
500 W
maximum rated load
1000 W
Sensitivity (1 W / 1 m)
101 dB
Frequency response
46 – 4000 Hz
Voice Coil Material
Aluminum
Magnet
Ferrite
Depth of the magnetic gap
9.53 mm
Thiele & Small Parameter
Fs (Resonance Frequency)
47 Hz
Re (DC resistance)
5.23 Ohm(s)
Qms (mechanical quality)
8.01
Le (inductance of the voice coil)
1.01 mH
Qes (electrical quality)
0.4
Qts (overall quality)
0.38
Vas (equivalent volume)
167.7
Mms (moving mass)
72 g
BL (power factor)
16.6 T/m
Xmax (maximum displacement)
3.2 mm
Cms (elasticity of the suspension)
0.16 mm/N
Sd (membrane area)
856.3 cm²
Weight
8,171 kg
