Eminence Basslite S 2012
Καλέστε μας για τιμή
Eminence Basslite S 2012
Κατόπιν παραγγελίας
- Περιγραφή
Περιγραφή
Eminence Basslite S 2012
BASSLITE® S2012
Recommended for bass guitar. Ideal in vented 1X, 2X, and 4 X12 enclosures
Product type
Loudspeaker Chassis
Type
Guitars
Nominal Diameter
12 “
Nominal Diameter
304.8 mm
Voice Coil
2 “
Voice Coil
50.8 mm
Overall diameter
305.5 mm
Pitch Circle Diameter
294.3 mm
Section Diameter
278.1 mm
Diameter of fixing holes
6.4 mm
Depth
130 mm
Nominal Impedance
8 Ohm(s)
Nominal Load Capacity
150 W
maximum rated load
300 W
Sensitivity (1 W / 1 m)
97 dB
Frequency response
49 – 4500 Hz
Voice Coil Material
copper
Magnet
Neodymium
Depth of the magnetic gap
7.2 mm
Thiele & Small Parameter
Fs (Resonance Frequency)
48 Hz
Re (DC resistance)
5.1 Ohm(s)
Qms (mechanical quality)
5.5
Le (inductance of the voice coil)
0.43 mH
Qes (electrical quality)
0.53
Qts (overall quality)
0.48
Vas (equivalent volume)
91
Mms (moving mass)
46 g
BL (power factor)
11.7 T/m
Xmax (maximum displacement)
5.2 mm
Cms (elasticity of the suspension)
0.24 mm/N
Sd (membrane area)
519.5 cm²
Weight
2,63 kg
